1700C Max. Dental Lab Equipment Zirconia Sintering Furnace for Tooth
Introduction of Zirconia Sintering Furnace
| Chamber size | Dia100xH100mm or 100x100x100mm |
| Max. temperature | 1700 oC (<2hour) |
| Working temperature | 800-1600 oC |
| Temperature controlling | - PID automatic control via SCR (Silicon Controlled Rectifier)power control with phase angle fired, current limiting resistor.
- Touch screen panel which can store 30pcs different programs
- Built in PID Auto-Tune function with overheating & broken thermocouple broken protection.
- Over temperature protection and alarm allows for operation without attendant.
|
| Temperature accuracy | ± 1 oC |
| Temperature Uniformity | ± 5°C |
| Heating rate | 0-30 oC /min |
| Thermocouple | B type (Pt-Rh to Pt-Rh) with 99.7% purity Alumina tube |
| Heating element | U type MoSi2 heating elements |
| Furnace Chamber | Three layers of ceramic fiber insulation materials - First layer: 1800°C ceramic fiber board
- Second layer: 1600°C ceramic fiber board
- Third layer: 1260°C ceramic fiber board
|
| Furnace structure | Double layer steel casing with dual cooling fan, surface temperature below 60oC |
| Furnace door | - Elevator opening with platform
- Power cutting off when furnace door open
|
| Outer dimension | About 550X420X810mm |
| Working voltage | 220V, 50HZ/60HZ, 1 phases (As per your order) |
| Rated power | 2KW |
How to control the temperature of zirconia sintering furnace
1) Adopt advanced AI artificial intelligence adjustment algorithm, no overshoot, can achieve any slope rise and fall control, with jump (cycle), run, pause and stop programmable / operational commands.
2) Measurement accuracy: 0.2 level
3) Alarm function: upper limit alarm, input open alarm.
4) 50 sections of program control functions
